Customized Portable Diesel Powered Hydraulic Power Pack For Field
Working
Product Introduction
The diesel hydraulic truck HS-36 consists of diesel engine and a
gear pump. Core parts are imported brands, which keeps machine in
stable and safe operation .The trolley body is controlled by touch
screen, which enables ease of operation and better display.
Industry Application
HS series of diesel hydraulic power units, can meet the
requirements of various industries, such as: Petrochemical Plant,
Power Station, Nuclear Power Station, , Boiler Plant, Refinery.
Features
■ The oil cooling system can ensure that the equipment operate
continuously within 40 ºC ambient temperature.
■ Portable, easy to handle with imported lightweight Core parts
with high quality and long service life.
■ It adopts step less speed control system to adjust the different
speed.
■ The quick connector can be quickly plugged and pulled without
leakage to ensure that users can quickly access.
■ Drilling and cutting can be achieved under the use of double oil
passages.
Technical Parameters
| Model | HS-36 |
| Drive mode | Diesel |
| Rated flow | Q=90L/min |
| Rated power | N=28KW(36HP) |
| Rated speed | n=2600 r/min |
| Rated pressure | P=15Mpa |
| Shipping dimensions | 1386x1200x1500(mm) |
| Shipping weight | 800kg |
Operating Steps of Hydraulic Unit
■ Select the suitable oil passage and connect the hose between the
operating valve block and the load. The fitting needs to be
tightened to ensure no oil leakage, also connect the hydraulic hose
to the hydraulic motor.
■ The machine needs to be heated when the ambient temperature is
below 10 ℃. The hydraulic oil will be automatically heated at low
temperatures. Just open the cabinet inside the inverter switch and
push the switch to “On”, the system will automatically preheat for
15mins, then the cabinet heats up the indicator lamp which will
always be on. The heat will be extinguished when the lamp is ended.
At the same time, make sure the ball valve handle is in the OFF
position, and then turn the start key to the START position to
start the diesel engine. For more detailed diesel engine
maintenance, please refer to the operating instructions of the
diesel engine.
■ Turn the ball valve in the figure below slowly clockwise (the
maximum rotation angle is 90 °) and observe the rotation speed of
the load to reach the appropriate speed.
■ Oil cooler governor valve and relief pressure regulator has been
adjusted before leaving the factory. It’s not necessary to operate
in the use of the process. And only need to adjust the
corresponding oil throttle valve to adjust the speed of the oil
load.
■ When finished, turn the ball valve counterclockwise to position
the ball valve handle and turn the control key to the OFF position
to stop the engine
Attention
■ Check whether the electrical component wirings are loose or false
welding.
■ Check the battery power.
■ Add low temperature anti-wear hydraulic oil from the oil filler of
tank to the top of fluid level meter. Fuel tank after refueling
should not immediately boot unless the bubble in the tank naturally
disappears. Relax the handle of the relief valve counterclockwise.
■ The distance between the diesel hydraulic power station and the
used equipment is at least 5 meters.
■ It is prohibited to connect the mechanical equipment and tools
which are easy to produce sparks with the diesel hydraulic power
unit.
